Fadal AC brushless amplifier AMP-0040 , front panel with FAULT LED indicator
Fadal AC brushless amplifier AMP-0040 , front panel with FAULT LED indicator

Photo Shown May Not Be Exact
Product photos are for reference and may vary by production run, revision, or supplier batch. Confirm fit against your machine's make, model, and part number before ordering. Questions on fit? Contact us before you order and we'll verify compatibility.

Fadal

Fadal - AC Brushless Amplifier, Rotary, Covered - AMP-0040

SKU: AMP-0040
(0)
$1,968.00 CAD

The AMP-0040 is the Glentek AC brushless amplifier used on Fadal VMCs running 8192 line motors. One card per axis, X, Y, Z, A, or B. When an axis stalls, chatters, or won't hold position, this is the amplifier most likely at fault. This is the original analog OEM card; a fully digital drop-in replacement is also available as the AMP-0040C.

Specifications ▼

Output Current

10A continuous, 20A peak

Encoder Line Count

8192 line, AC brushless

Motor Compatibility

Glentek MTR-0142, Baldor MTR-0146

Overload Protection

Current and temperature sensors built in. Folds back to continuous output after 3 seconds at peak rather than shutting down outright.

Fault Codes ▼

Fault Code 1

"No motor feedback" — appears on power up if no motor feedback (resolver or encoder) or no motor motion is detected by the axis controller.

Fault Code 18

"Servo amplifier fault line down" — the axis card no longer detects the fault line signal from the amplifier, or the signal strength drops below 10V. Check the amplifier's front-panel FAULT LED first.

Compatible Machines ▼

Fadal VMC 4020, 4525, 5020A, 6030, 6535, 8030

All models using 8192 line AC brushless motors with metric pitch ballscrews. Axes covered: X, Y, Z, A, B. Confirm your motor type before ordering.

Important Information ▼

Usually In Stock

Contact us to confirm current availability before ordering.

Cross-Reference

Replaces AMC AMP-0034 and Glentek AMP-0029

Also Needed For This Job ▼

Also Needed For This Job

Prefer the fully digital version with surface-mount components and better long-term reliability? See the AMP-0040C digital drop-in replacement; same wiring, same pot adjustment, no reconfiguration needed. If all three axes on the same chassis are failing, you may need the full AMP-0028 chassis assembly instead.
