Fadal Glentek AC Brushless Amplifier — AMP-0040C

The AMP-0040C is a fully digital AC brushless servo amplifier manufactured by Glentek, designed as a direct drop-in replacement for the legacy analog AMP-0040. Surface-mount components replace through-hole design throughout, matching the performance of the original while significantly improving long-term reliability.

Part number cross-reference: Fadal AMP-0040C - replaces AMP-0040 · AMC AMP-0034

Electrical specifications:

• Encoder type: 8192 line AC brushless
• Output: 10 amps continuous, 20 amps peak
• Design: Digital surface-mount - direct analog replacement

Compatible motors: Glentek MTR-0142 · Baldor MTR-0146

Compatible Fadal VMC models: VMC 4020 · VMC 4525 · VMC 5020A · VMC 6030 · VMC 6535 · VMC 8030 — all models using 8192 line AC brushless motors with metric pitch ballscrews

Axes covered: XYZAB — all axis positions using 8192 line AC brushless configuration

Drop-in installation: Wiring is identical to the AMP-0040. Pot location and adjustment is the same. Produces identical ballbar results as the legacy version, which means no reconfiguration required after swap.

Important before ordering: The AMP-0040C is for machines running 8192 line AC brushless motors. If your Fadal uses DC brush motors or 5000 line AC motors, this is not the correct amplifier. Confirm your motor type before ordering. Unsure? Submit an RFQ with your VMC model and motor part number and we will verify the correct amplifier for your machine.
