Fadal - AC Amplifier Chassis & Power Supply - AMP-0038
Regular price
$7,300.00 CAD
Couldn't load pickup availability
The AMP-0038 is the complete AC servo amplifier chassis for smaller, linear-way Fadal VMCs running 5000 line brushless motors: power supply, 5-slot chassis, and three AMP-0039 amplifier cards for X, Y, and Z axes, fully wired and ready to install. When this chassis fails, all three axes go down at once, not one. This is the OEM-spec assembly, not a single replacement card.
Specifications ▼
Output Voltage
330 to 360V DC
Configuration
5-slot chassis: X, Y, Z populated; A, B open for rotary axis expansion
Amplifier Cards Included
3x AMP-0039, 5000 line encoder, brushless AC, for X, Y, Z axes
Safety
Contactor wired to Emergency Stop circuit
Included Hardware
External REGEN resistor and mounting hardware
Fault Codes ▼
Fault Code 1
"No motor feedback," which appears on power up if no motor feedback (resolver or encoder) or no motor motion is detected by the axis controller.
Fault Code 18
"Servo amplifier fault line down," meaning the axis card no longer detects the fault line signal from the amplifier, or the signal strength drops below 10V.
Compatible Machines ▼
Fadal VMC 3016 and other linear-way VMCs, 1997 or newer
Smaller linear-way Fadal VMCs using 5000 line AC brushless motors. Confirm your motor type before ordering.
Important Information ▼
Usually In Stock
Contact us to confirm current availability before ordering.
VMC15 / VMC2016L Owners
Whether your machine uses 5000 line motors depends on production year. Submit an RFQ with your motor part number to confirm before ordering.
Individual Components Also Available
Need just the amplifier card, not the full chassis? See AMP-0039 below.
Also Needed For This Job ▼
Also Needed For This Job
If only one axis failed, you may not need the full chassis. Check the individual AMP-0039 amplifier card first (5000 line, XYZAB, sold separately).
